3 Watt Mini LED; G4 Base; 3000K; Clear Finish; 12 Volt (S12120)
Image may not reflect selected features
No Image
Available
Available
BASE PRICE:
$
7
90
/
/ 1
($7.90 / 1)
WAS
$
Call for Price
+
-
Add To Cart
Add To Estimate
Add To Wishlist
Save To Compare
Item #:
S12120
Dimensions:
Width: 0.63"
Clear
Availability:
- Manufacturer has 985 items available.
Description
Details
Downloads
3 Watt Mini LED; G4 Base; 3000K; Clear Finish; 12 Volt
Category:
Light Bulbs
Subcategory:
LED Bulbs
Category:
LED
Sub-Category:
Mini and Pin-Based LED
Volts:
12V
Bulb Dimmable:
Yes-Dimmable
Bulb Hours:
25000
Bulb Kelvin:
3000K
Bulb Shape:
T5
Diameter:
0.63
EA Length:
3.27
Harmonized Codes:
8539.52.0091
Length:
1.69
Lumens:
330L
Shap Carton Width:
0.63
Ship Carton Height:
4.84
Ship Weight:
0.06
Warranty:
3 Year Limited - Mini LED Pin Base
Weight:
0.02
Additional Info:
Housing Material: Ceramic; Lens Material: Polycarbonate (PC)
Beam Spread:
300
Bulb ANSI Base:
G4
Bulb Base:
Bi Pin G4
Bulb Finish:
Clear
Candle Power:
30
Carton Cubic Feet:
0.0058
Cartons Per Unit:
1
CCT Selectable:
No
CEC:
Exempt - Base Not Regulated
CEC Terse:
Lawful for sale in California
CEC Web Text:
Lawful for sale
Color Temprature:
Soft White
Country Of Origin:
China
CRI:
80
Dimmable Down To:
100 to 10 percent
Dimmable Function:
Check the transformer/driver MFG for dimmer compatibility
Dimming Type:
Phase cut
Efficacy:
110.00 LPW
Enclosed Fixture Use:
Yes
Enclosure Rating:
Enclosed Rated Lamp
FCC Compliant:
Yes
Feature 1:
Low 12-volt Operation
Feature 2:
300 degree Omni-Directional Light
Feature 3:
3000K CCT
Feature 4:
Damp location rated
Feature 5:
T5, Bi-Pin G4 Base
Feature 6:
Dimmable
Feature 7:
25,000 Life Hours
Housing Color:
White
Incandescent Equivalent:
25W
Indoor Outdoor:
Indoor
Installation Notes:
Not for use in vapor tight fixtures.
Lamp Filament:
LED
Location Rating:
Damp
Long Description:
Illuminate your surroundings while maximizing energy efficiency and cost-effectiveness with SATCO|NUVO's S12120 3-watt, G4-base, Halogen replacement lamp. Engineered for low 12-volt operation and featuring 300-degree omni-directional lighting, this lam
Material:
Ceramic / Polycarbonate (PC)
Operating Frequency:
60Hz
Operating Temp:
-20C (-4F) to +40C (+104F)
Order In Multiples Of:
1
Pack Type:
Carded
Power Factor:
0.7
Quantity In Pack:
1
RoHS Compliant:
Yes
Romance Copy:
Illuminate your surroundings while maximizing energy efficiency and cost-effectiveness with SATCO|NUVO's G4 and GY6.35 Halogen replacement lamps. Available in an array of shapes, bases, and finishes, these lamps are equipped with LED technology, ensuri
Short Description:
3W/LED/G4/CL/830/12V/1CD
Style:
Utility
Surge Protection:
Built-in surge protection - 1.5KV
Technology:
LED
Title 20 Compliant:
No
Title 24 Compliant:
No
Total Harmonic Distortion:
70%
Wattage Selectable:
No
Watts:
3W
